SPE ACCE 2025 - Efficient Simulation for Hybrid Overmolded Composite Lattice Structures: A Combined Implicit and Explicit FEA Approach


WEAV3D presents an Efficient Simulation for Hybrid Overmolded Composite Lattice Structures: A Combined Implicit and Explicit FEA Approach at SPE ACC 2025.This paper presents a hybrid workflow: multiscale modeling enables quick stiffness evaluation and guide design iteration, while discrete modeling is applied to critical designs for detailed stress and strain analysis. The hybrid workflow is demonstrated on a heavy truck component to illustrate how the combined approach improves computational efficiency in part-level analysis of lattice-reinforced composites.

Download the PaperDownload the Presentation

SPE ACCE 2025 - Paper Composites reinforced with GFPP or NFPP Lattices


WEAV3D’s President and Chief Engineer – Chris Oberste – presents Paper Composites Reinforced with GFPP or NFPP Lattices in conjunction with the University of Tennessee Knoxville and Volkswagen at SPE Automotive ACCE Conference 2025.

Download the Presentation

SPE ACCE 2024 - Cost Effective Thermoplastic Body Structures


WEAV3D has developed a novel hybrid-material approach, Rebar for Plastics®, that combines existing thermoforming, compression molding or injection overmolding processes with woven composite lattices formed from unidirectional thermoplastic tapes to produce high-rate, cost-effective structural composites. The resulting structural panel exhibits high stiffness, strength, and ductility, equivalent or better than sheet metal, while offering weight savings of up to 65% compared to steel. In partnership with Braskem, Altair, and the Clemson Composites Center, an automotive door structure originally developed in carbon fiber/PA6 organosheet was redesigned as a lattice reinforced polypropylene panel. A case study covering design, manufacturing, and testing of this innovative thermoplastic composite structure will be presented, showcasing 20% weight savings and 50% cost savings vs. organosheet, while also reducing trim scrap mass by 63%. This presentation will also discuss how OEMs and Tier suppliers can adapt this cost-effective lattice-reinforced approach to other vehicle components and molding processes.

Download the Presentation

SPE ACCE 2024 - Composite Lattice Reinforced Part Optimization with FEA: An Automotive Door Component Case Study


This paper presents a finite element analysis (FEA) method of modelling automotive components reinforced with WEAV3D composite lattice structures. WEAV3D Inc. has developed a novel hybrid-material approach, Rebar for Plastics®, merging existing thermoforming, compression molding or injection overmolding processes with woven composite lattices formed from unidirectional thermoplastic tapes to produce high-rate, cost-effective structural composites. These materials pose challenges for conventional composite FEA modeling, demanding advanced techniques for accurate mechanical predictions, especially in structural applications.
Presented FEA methodology addresses these challenges by enabling explicit modeling of lattice designs using Altair HyperMesh. By parameterizing tape materials, spacing, and layer count through scripting, the methodology streamlines design exploration, eliminating the need for CAD models for each iteration and enabling regional optimization within the part. This optimizes lattice structures efficiently to achieve desired mechanical properties at the part level.
Through a case study of an automotive door component, we demonstrate the applicability of our FEA workflow. Comparison of FEA predictions with experimental data validates the reliability of the model. These results highlight the efficacy of our methodology in predicting mechanical behavior, suggesting its potential to guide design decisions across various industrial applications through optimization.

Download the PresentationDownload the Paper

A Multiscale Approach to the Design and Analysis of WEAV3D Lattice Structures


Altair Vice President of Composite Technology & Aerospace Strategy, Jeffrey A. Wollschlager presents “A Multiscale Approach to the Design and Analysis of WEAV3D Lattice Structures” at the ASME 2024 Aerospace Structures, Structural Dynamics, and Materials Conference.

Download the Paper

ANTEC 2024 - Cost-Effective Automotive Body Structures


WEAV3D has developed a novel hybrid-material approach, Rebar for Plastics®, that combines existing thermoforming, compression molding or injection overmolding processes with woven composite lattices formed from unidirectional thermoplastic tapes to produce high-volume, low-cost structural composites. The resulting structural panel exhibits high stiffness, strength, and ductility, equivalent or better than sheet metal, while offering weight savings of up to 65% compared to steel.

In partnership with Braskem, Altair, and the Clemson Composites Center, an automotive door structure originally developed in carbon fiber/PA6 organosheet was redesigned as a lattice reinforced polypropylene panel. This highly optimized structure achieved 20% weight savings and 50% cost savings vs. the original organosheet, while also reducing trim scrap mass by 63%. The FEA design process and experimental results will be presented, as well as a cost and performance comparison against the original organosheet design.

Download the Full PresentationDownload the Reduced Size Presentation

Rebar for Plastics: Enabling Cost Effective Body Structures


In partnership with Braskem, Altair, and the Clemson Composites Center, an automotive door structure originally designed in carbon fiber/PA6 organosheet was redesigned utilizing WEAV3D’s Rebar for Plastics® design methodology, which leverages various micro-and macro-mechanical concepts to maximize performance and minimize cost in hybrid length-scale composites. This highly optimized structure achieved 20% weight savings and 50% cost savings vs. the original organosheet, while also reducing trim scrap mass by 63%.

Watch the VideoRead the Application Note

WEAV3D to present at CAMX 2023 in Atlanta, GA.


CAMX

Rebar for Plastics – A Novel Approach to Part Optimization with Hybrid Length-Scale Composites

Download the Paper

A Revised Finite Element Analysis Approach to Designs and Optimize Composite Lattice Reinforcements and Simulate the Mechanical Properties of Composite Lattice Reinforced Plastics

Download the Paper

Structural Enhancement of Sustainable Materials


The automotive industry has committed to increasing the use of sustainable materials in order to meet long term embodied carbon and circular economy goals. “Sustainable” materials are not clearly defined, but generally include natural fillers and fibers, polymers produced from bio-renewable feedstocks, and post-consumer and post-industrial recycled polymers. While bio-renewable feedstocks are largely equivalent to petroleum-based feedstocks in final polymer performance, natural fibers and recycled materials suffer from reduced and inconsistent mechanical properties compared to their synthetic or virgin alternatives. A significant portion of plastic components in the vehicle today are glass reinforced, presenting a substantial performance barrier to the adoption of natural fibers.

WEAV3D has developed a novel hybrid-material approach, Rebar for Plastics®, that dramatically improves the performance of sustainable materials, through a combination of natural fiber reinforced polypropylene (NFPP) mats and woven composite lattices formed from unidirectional tapes.

Download the PresentationWatch the Presentation

Numerical Modeling of the Bond Behavior Between Thermoplastic FRP Lattice and Concrete


Replacing steel bars with fiber-reinforced polymer (FRP) bars is widely acceptable as a potential solution to eliminate the corrosion problem in reinforced concrete structures. This paper examines another option to resolve this problem, which utilizes a novel composite lattice material manufactured by WEAV3D Inc. The composite lattice is manufactured by weaving and bonding thermoplastic FRP tapes using an innovative lattice-forming process. Accurate representation of the bond between this lattice and concrete is needed to be able to utilize it in structural concrete elements. In this paper, numerical modeling of the bond between WEAV3D composite lattice and concrete is examined. The model predictions were validated using experimental data.

Download the Paper

Braskem Takes Polypropylene to the Next Level of Performance in Partnership with WEAV3D® utilizing its Rebar for Plastics® Lattice Technology

This solution combines Braskem’s polypropylene sheets with WEAV3D lattice technology to address new structural and automotive applications requiring high-strength, lightweight material solutions.  Braskem to present its PP solutions with WEAV3D lattice technology at the 2023 SPE® TPO Global Automotive Conference in Detroit, October 1-4

Read MoreDownload the One Pager

IMPROVING NATURAL-FIBER REINFORCED POLYPROPYLENE

Natural-fiber reinforced thermoplastic composites have recently emerged as a lightweight, sustainable alternative to glass reinforced plastics for automotive interior applications such as package shelves, luggage compartment components, load floor and SUV cargo decks.

Read More

POLYMER CONCRETE REINFORCEMENT

Polymer concrete has traditionally been reinforced with steel rebar, but WEAV3D composite lattice technology has emerged as a superior reinforcement system that offers corrosion resistance and design freedom not possible with rebar cages. Unlike steel, our patented and patent-pending thermoplastic composite lattice forms an adhesive bond with the polymer concrete, enhancing the impact strength and other mechanical properties of the finished concrete part.

Read More

NEW OLDCASTLE CABLE TRENCH OVERCOMES CHALLENGES OF STEEL REINFORCEMENT, THANKS TO WEAV3D COMPOSITES

Cable trenches play an important role in managing and distributing cables and wires in utility, rail and power applications. Oldcastle, a leading provider of building materials, supplies these durable components in the form of its polymer-based concrete trench systems. By using a patented material, these trenches offer exceptional H-20 loading at 25-percent less weight than traditional concrete. They also feature an excellent strength-to-weight ratio, reduce installation costs and provide a safer, more cost-effective option compared to concrete trenches.

Read More
